What data does this use?

Enter pore area, analyzed electrode area, thickness measurements, crack length, and field area.

Does this analyze images directly?

No. It calculates from measurements exported from image analysis.

Is this an acceptance tool?

No. It is for research summaries and protocol documentation.

ToolsConductScience tool

BatteryFree in-browser calculator

Battery Electrode Porosity Calculator.

Summarize pore area, coating thickness, and crack length measurements for electrode cross-sections. For materials research, education, and protocol documentation only. Not a certified inspection, compliance, asset-integrity, or final acceptance tool.

Run calculator Request a Quote

PrivateData stays in your browser

LiveNo sign-up required

Validated2026-05-24

CitableMethods and citation included

Calculator

Results update in place

Try it out

Load example electrode porosity data to see the full workflow

Electrode Porosity inputs

Pore area

um2

Electrode area

um2

Thickness values (um)Total crack length

Field area

mm2

Results

Porosity

16.8 %

Mean thickness

83.5 um

Thickness SD

2.878 um

Crack density

2240 um/mm2

Review notes

Electrode porosity depends on segmentation, section prep, field selection, and binder contrast.

Methods note

Porosity equals pore area divided by total electrode area. Crack density equals crack length divided by field area.

Scope and limitations

For materials research, education, and protocol documentation only. Not a certified inspection, compliance, asset-integrity, or final acceptance tool.

Results are deterministic calculations from the values entered here. Review units, assumptions, and measurement quality before using outputs in reports or protocols.

Method

Uses the tool-specific formulas and assumptions shown in the calculator output.

Validated

Last validated 2026-05-24. Calculations are designed for planning and documentation support; verify procurement decisions against manufacturer specifications or institutional SOPs.
