Enter the total solder joint area and a list of measured void areas in the same unit family.

Does this certify acceptability?

No. It is a measurement summary tool, not an acceptance or compliance tool.

Can image-derived areas be used?

Yes. Enter areas exported from microscopy, x-ray, or image-analysis workflows.

ToolsConductScience tool

SolderFree in-browser calculator

Solder Joint Void Calculator.

Summarize measured solder-joint void areas without certified inspection claims. For materials research, education, and protocol documentation only. Not a certified inspection, compliance, asset-integrity, or final acceptance tool.

Run calculator Request a Quote

PrivateData stays in your browser

LiveNo sign-up required

Validated2026-05-24

CitableMethods and citation included

Calculator

Results update in place

Try it out

Load example solder voids data to see the full workflow

Solder Voids inputs

Joint area

um2

Void areas (um2)

Results

Void fraction

1.468 %

Void count

Largest void

850 um2

Void 1

850

Void 2

420

Void 3

310

Void 4

160

Void 5

Review notes

Segmentation threshold and projection geometry can change measured void fraction.

Methods note

Void percent equals total void area divided by joint area.

Scope and limitations

For materials research, education, and protocol documentation only. Not a certified inspection, compliance, asset-integrity, or final acceptance tool.

Results are deterministic calculations from the values entered here. Review units, assumptions, and measurement quality before using outputs in reports or protocols.

Method

Uses the tool-specific formulas and assumptions shown in the calculator output.

Validated

Last validated 2026-05-24. Calculations are designed for planning and documentation support; verify procurement decisions against manufacturer specifications or institutional SOPs.

How to cite

How to Cite

Solder Joint Void Calculator (1.2.0). ConductScience, Inc. 2026. Available at: https://conductscience.com/tools/solder-joint-void-calculator

For materials research, education, and protocol documentation only. Not a certified inspection, compliance, asset-integrity, or final acceptance tool.
