Fish Detour Task Apparatus
Two-tank, four-compartment detour apparatus for studying goal-directed navigation and object-location responses in zebrafish and other freshwater fishes.
Louise Corscadden, PhD
Director of Science · ConductScience
Ask Louise about Fish Detour Task Apparatus fit, setup, configuration, or quote prep.
Already working with us? Sign in to connect this with My Scientist.
Key Specifications
Full details →- Model fit
- Zebrafish, goldfish, redtail splitfin, and freshwater angelfish
- SKU family
- Assigned during quote
- Sizing
- Model-specific dimensions confirmed from the selected configuration
- Ordering
- Quote-reviewed before fulfillment
- Category
- Behavioral Mazes
- Build notes
- Confirm accessories, station layout, and support needs before purchase
The Fish Detour Task Apparatus recreates the published four-compartment aquatic task in which a subject observes a social goal through a window, exits a central corridor, and chooses among compartments near or far from that goal.
Paper-defined two-tank system
The validated reference is a pair of physically separate glass tanks facing each other, with their adjacent walls left uncovered. A custom corridor-and-partition insert can be evaluated only after the laboratory supplies the exact internal tank dimensions. The final drawing confirms every aperture, barrier, divider, water depth, tank alignment, and mounting interface.
Source-backed multi-species geometry
The published apparatus was used with zebrafish, goldfish, redtail splitfin, and freshwater angelfish. Species-specific husbandry and study procedures remain under the laboratory protocol.
Features & Benefits
Published species
- Zebrafish, goldfish, redtail splitfin, and freshwater angelfish
Experimental tank
- 35 cm × 30 cm × 28 cm
Social-attractor tank
- 25 cm × 25 cm × 25 cm
Published water depth
- 19 cm
Central corridor
- 24 cm long × 22 cm high; walls spaced 9 cm
Observation window
- 5 cm × 14 cm with grid
Choice apertures
- Two symmetrical 4 cm openings
Partitions
- Four 5 cm × 22 cm partitions at 45 degrees
Order basis
- Complete two-tank system; custom insert only after compatibility engineering
Practical Tips
Match water depth and the two adjacent viewing walls.
Why: The source setup creates a continuous view between subject and goal tanks.
Provide the base-tank internal dimensions before ordering an Insert Kit.
Why: Aperture and divider positions depend on the usable internal tank geometry.
Setup Guide
What’s in the Box
- Complete two-tank apparatus or custom insert scope identified in the approved quote
- Corridor, observation window, sliding panel, and four diagonal partitions for the approved configuration
- Final component schedule matched to the fabrication drawing
Warranty
Fabrication support, replacement options, and warranty terms are confirmed with the final drawing and quote.
References
Background reading relevant to this product:
Was this apparatus used with zebrafish?
Yes. Zebrafish were one of four freshwater species tested in the published apparatus.
What is the difference between the complete system and a custom insert?
The complete system follows the paper-defined two-tank relationship. A custom insert is not assumed compatible and is quoted only after the base tank dimensions and viewing geometry pass engineering review.
How many choice compartments are there?
Four: two near the social goal and two on the opposite side of the experimental tank.
Does the apparatus include recording equipment?
The choice area supports overhead recording. Camera and analysis systems are configured separately.
