R20PC-Full – Smartlid for Ancare R20PC / NexGen / Innovive
AI-powered behavioral monitoring system for Ancare-compatible rodent cages providing continuous infrared video tracking and environmental sensing for comprehensive home cage behavioral analysis.
Louise Corscadden, PhD
Director of Science · ConductScience
Ask Louise about R20PC-Full – Smartlid for Ancare R20PC / NexGen / Innovive fit, setup, configuration, or quote prep.
Already working with us? Sign in to connect this with My Scientist.
The R20PC-Full Smartlid is an AI-powered behavioral monitoring system designed specifically for Ancare R20PC, NexGen, and Innovive laboratory rodent cages. This system provides continuous 24/7 behavior tracking through integrated infrared video analysis, edge computing capabilities, and environmental sensors mounted directly on the cage housing.
The system captures comprehensive behavioral data including locomotor activity patterns, circadian rhythms, and detailed ethograms without requiring animal handling or disrupting normal housing conditions. Edge computing processes video data locally, reducing bandwidth requirements while providing real-time behavioral analysis. Environmental sensors monitor cage conditions simultaneously with behavioral tracking, enabling correlation between environmental parameters and animal behavior patterns.
How It Works
The R20PC-Full Smartlid utilizes infrared video capture technology combined with machine learning algorithms for real-time behavioral analysis. Infrared illumination enables continuous monitoring regardless of light cycle conditions while minimizing visual disturbance to the animals. Computer vision algorithms track animal position, movement patterns, and posture changes throughout the monitoring period.
Edge computing architecture processes video streams locally within the smartlid unit, extracting behavioral metrics without requiring constant network connectivity. Environmental sensors integrated into the system monitor temperature, humidity, and other cage parameters, correlating environmental conditions with observed behavioral patterns. Data processing algorithms generate comprehensive ethograms, activity maps, and temporal behavioral profiles.
The system integrates directly with existing Ancare R20PC and compatible cage systems, replacing standard cage tops without requiring modifications to existing housing infrastructure. All data collection occurs passively without animal handling or experimental intervention, maintaining natural behavioral expression in the home cage environment.
Features & Benefits
Behavioral Construct
- locomotor activity
- circadian rhythms
- activity patterns
- sleep-wake cycles
- spontaneous behavior
- behavioral phenotyping
- home cage behavior
Automation Level
- fully-automated
Research Domain
- Aging Research
- Anxiety and Depression
- Behavioral Pharmacology
- Learning and Memory
- Motor Function
- Neurodegeneration
- Neuroscience
- Social Behavior
- Toxicology
Species
- Mouse
- Rat
Weight
- 6.06 kg
Dimensions
- L: 65.0 mm
- W: 36.0 mm
- H: 27.0 mm
| Feature | This Product | Typical Alternative | Advantage |
|---|---|---|---|
| Monitoring Integration | Direct cage-top integration with Ancare R20PC and compatible systems | Separate monitoring chambers requiring animal transfer | Eliminates handling stress and provides behavioral data in the natural housing environment. |
| Data Processing Architecture | Edge computing with local processing capabilities | Cloud-based processing requiring continuous network connectivity | Reduces network dependencies and enables real-time analysis with immediate alert capabilities. |
| Environmental Integration | Combined behavioral and environmental sensor monitoring | Behavioral monitoring only or separate environmental systems | Enables correlation analysis between environmental conditions and behavioral responses in a single system. |
| Infrared Monitoring Technology | 24/7 infrared video tracking regardless of light cycle | Visible light systems limited to light cycle periods | Provides complete circadian rhythm analysis without disrupting natural light-dark cycles. |
The R20PC-Full Smartlid offers integrated home cage behavioral monitoring with edge computing capabilities and environmental sensor integration. The system provides continuous infrared video analysis specifically designed for Ancare-compatible cage systems, enabling naturalistic behavioral data collection without animal handling requirements.
Practical Tips
Perform initial system calibration with empty cages before introducing animals to establish baseline parameters and verify proper sensor operation.
Why: Ensures accurate behavioral detection algorithms and environmental sensor readings from the start of data collection.
Allow 24-48 hours after cage setup before beginning data collection to permit animal acclimation to any minor environmental changes.
Why: Eliminates potential behavioral artifacts from housing transitions that could confound experimental results.
Monitor initial behavioral tracking results to verify proper animal detection and movement pattern recognition before starting long-term studies.
Why: Early verification prevents loss of data from tracking errors during extended monitoring periods.
Clean infrared sensors and camera lenses weekly using appropriate cleaning solutions to maintain optimal video quality.
Why: Dust and debris accumulation can reduce tracking accuracy and compromise behavioral data quality over time.
Check network connectivity and data synchronization status daily, especially during critical experimental periods.
Why: Network interruptions can cause data gaps that may compromise longitudinal behavioral analysis.
Ensure proper ventilation is maintained when installing the smartlid unit to preserve normal cage airflow patterns.
Why: Adequate ventilation is essential for animal welfare and prevents environmental parameter changes that could affect behavior.
Setup Guide
What’s in the Box
- R20PC-Full Smartlid unit (typical)
- Power adapter and cables (typical)
- Network connectivity cables (typical)
- Installation hardware and mounting components (typical)
- User manual and setup documentation (typical)
- Software access credentials and configuration guide (typical)
Warranty
ConductScience provides a one-year manufacturer warranty covering hardware components and technical support for system setup and operation. Extended warranty and calibration service options are available for long-term research applications.
Compliance
What cage systems are compatible with this smartlid?
The R20PC-Full is specifically designed for Ancare R20PC, NexGen, and Innovive cage systems, providing direct replacement for standard cage tops without requiring housing modifications.
How does infrared monitoring affect animal behavior?
Infrared illumination operates outside the visible spectrum for rodents, enabling continuous monitoring without disrupting natural circadian rhythms or introducing visual stimuli that could alter behavior patterns.
What behavioral parameters can be measured?
The system tracks locomotor activity, position mapping, movement patterns, activity duration, circadian rhythm analysis, and generates comprehensive ethograms with temporal behavioral profiling capabilities.
How is data processed and stored?
Edge computing processes video data locally within the smartlid unit, generating behavioral metrics and environmental data that can be stored locally or transmitted to laboratory data management systems.
What environmental parameters are monitored?
Integrated sensors monitor cage microenvironment conditions, though specific parameter ranges and sensor types should be confirmed from the product datasheet.
Can multiple units be operated simultaneously?
The system supports multi-cage monitoring setups, though network requirements and data management protocols for large-scale deployments should be verified during system planning.
What are the power and connectivity requirements?
The system requires standard electrical power and network connectivity for data synchronization, though specific power consumption and network bandwidth requirements should be confirmed from technical specifications.
