Body Composition Imaging Analyzer
Advanced QMR12-060H-I body composition imaging analyzer for 15-150 g small-animal studies that need fat/lean quantification plus qualitative fat-distribution imaging.
Louise Corscadden, PhD
Director of Science · ConductScience
Ask Louise about Body Composition Imaging Analyzer fit, setup, configuration, or quote prep.
Already working with us? Sign in to connect this with My Scientist.
Key Specifications
Full details →- Modes
- Body composition quantification, Localized imaging, Whole-body imaging
- Model
- QMR12-060H-I
- Suitable For
- Small animals 15-150 g, Ex vivo tissues 0.1-6 g
- Technology
- Low-field quantitative magnetic resonance with imaging
- Magnet Type
- Permanent magnet
- Magnetic Field Strength
- 0.3 +/- 0.03 T
The Body Composition Imaging Analyzer maps to the QMR12-060H-I source model. It is the advanced option in the small-animal body-composition line for studies that need quantitative body-composition measurement plus qualitative imaging of fat distribution.
Best-fit applications
- Metabolic phenotyping studies requiring both body-composition quantification and fat-distribution imaging
- Longitudinal obesity, diabetes, nutrition, drug-efficacy, aging, cardiovascular, and toxicology workflows
- Studies where whole-body or localized imaging adds context to fat and lean mass measurements
Source-backed configuration
- Source model: QMR12-060H-I
- Sample range: small animals from 15-150 g
- Ex vivo tissue range: 0.1-6 g
- Magnet: permanent magnet, 0.3 +/- 0.03 T
- Measurement speed: completes analysis within 80 seconds
- Functional scope: body-composition quantification plus localized or whole-body imaging for quantitative and qualitative evaluation
- Measured outputs supported by source page: fat content, lean mass, and full body-composition testing
Important quote note
This product should be quoted as an advanced imaging-capable QMR configuration, not as a QMR06 model. Final bore size, spectroscopy scope, included components, dimensions, facility requirements, warranty terms, and supplier cost must be confirmed before automatic quoting.
Choose the right QMR body-composition configuration
Mouse and rat body-composition analyzers are consolidated as QMR06 configuration choices. Compare QMR06 mouse configuration (QMR06-060H-PRO; Mice 10-100 g; tissues 0.1-6 g; best fit: Mouse metabolic phenotyping and repeated fat/lean/free-water measurement); QMR06 rat / larger small-animal configuration (QMR06-090H-PRO; Small animals 10-800 g; tissues 0.1-6 g; best fit: Rat and larger small-animal metabolic phenotyping); QMR12 imaging-capable option (QMR12-060H-I; Small animals 15-150 g; tissues 0.1-6 g; best fit: Body-composition quantification plus qualitative fat-distribution imaging) is the current configuration. Compare all small animal body-composition configurations. ConductScience keeps the QMR12 imaging-capable analyzer as a separate advanced option and confirms included accessories, installation requirements, and support scope before quote.
How It Works
The QMR12-060H-I combines quantitative magnetic resonance body-composition measurement with imaging capability. The source page supports a 0.3 +/- 0.03 T permanent magnet, 15-150 g small-animal range, and 0.1-6 g ex vivo tissue range.
This configuration is the advanced option for studies that need fat and lean mass quantification plus qualitative visualization of fat distribution.
Features & Benefits
Modes
- Body composition quantification
- Localized imaging
- Whole-body imaging
Model
- QMR12-060H-I
Suitable For
- Small animals 15-150 g
- Ex vivo tissues 0.1-6 g
Technology
- Low-field quantitative magnetic resonance with imaging
Magnet Type
- Permanent magnet
Magnetic Field Strength
- 0.3 +/- 0.03 T
Measurement Speed
- <= 80 seconds
Measured Outputs
- Fat content
- Lean mass
- Full body composition
Quote Status
- Price/configuration reconciliation required before automated quote
Research Domain
- Metabolic Research
- Obesity Research
- Diabetes Research
- Nutrition Research
- Pharmaceutical QC
- Toxicology
Shipping weight
- 350.0 lb
Shipping box
- L: 100.0 cm
- W: 80.0 cm
- H: 100.0 cm
What’s in the Box
- QMR12-060H-I imaging-capable body-composition analyzer
- Imaging/body-composition software package to be confirmed
- Animal handling and positioning accessories to be confirmed
- Calibration accessories to be confirmed
- Final included components confirmed in quote
Warranty
Warranty, training, installation, and included components must be confirmed before quote for the QMR12-060H-I configuration.
Compliance
Datasheet
Specifications, models, materials, and operating envelopes
