ST300FC High-Torque Multi-Head Dispensing Peristaltic Pump

Overview

The ST300FC High-Torque Multi-Head Dispensing Peristaltic Pump combines basic, flow-rate, and dispensing functions in a single versatile instrument. Powered by a servo motor drive system, this pump delivers exceptional torque and precision for demanding laboratory applications. The 304 stainless steel construction ensures chemical compatibility and durability in corrosive environments.

Key Features

Features a 4.3-inch industrial-grade full-color touchscreen that displays critical operating parameters including dispensing volume, dispensing time, interval time, and cycle count. The pump supports multiple pump head types including YZ1515, YZ2515, and KZ25, providing flexibility for various tubing sizes and flow requirements. Speed control ranges from 0.01 to 300 rpm with exceptional precision. Advanced dispensing capabilities include programmable volume control from 0.01mL to 9999.99mL, cycle counting from 0 to 9999 cycles (0 for infinite operation), and interval timing from 0.5 to 9999.99 seconds. The anti-drip suck-back function with 0-360° angle adjustment prevents cross-contamination and waste.

Applications

Ideal for automated liquid handling, precise reagent dispensing, pharmaceutical formulation, chemical synthesis, and analytical sample preparation. The external control interfaces (0-5V, 0-10V, 4-20mA, 0-10kHz) and RS485 communication enable seamless integration into automated systems and process control networks. Perfect for applications requiring consistent, repeatable dispensing with minimal operator intervention.
