Manifolds Vacuum Filtration
Multi-port vacuum filtration manifold for simultaneous filtration of multiple samples. Corrosion-resistant design with individual port control valves. Ideal for microbiological and environmental analysis.
| Funnel | Connection |
| Holder | Package Size(W*D*H) |
| MVF-1G | 1-branch |
| Glass | Ground Joint |
| SS316 | 970*360*370mm |
| MVF-1S | SS316 |
The Manifolds Vacuum Filtration system enables simultaneous filtration of multiple liquid samples through membrane filters under controlled vacuum conditions. The stainless steel manifold body accommodates standard 47 mm membrane filters and integrates with a graduated glass or polypropylene receiver flask for each position. Individual PTFE stopcocks allow sequential or parallel sample processing with independent flow control per port.
Ideal for microbiological analysis of water, beverages, and environmental samples per standard methods including SM 9222, EPA 1103.1, and ISO 9308. Compatible with 0.22 and 0.45 µm cellulose acetate, PVDF, and nylon membranes. Autoclavable at 121°C for sterile filtration applications.
Funnel
- Connection
Holder
- Package Size(W*D*H)
MVF-1G
- 1-branch
Glass
- Ground Joint
SS316
- 970*360*370mm
MVF-1S
- SS316
Integral, SS316
- SS316
270*260*140mm
- 3kg
MVF-3G
- 3-branch
MVF-3S
- SS316
490*260*140mm
- 5.7kg
MVF-6G
- 6-branch
MVF-6S
- SS316
920*260*140mm
- 10.3kg
Brand
- ConductScience
Weight
- 29.98 kg
Dimensions
- L: 42.0 mm
- W: 43.6 mm
- H: 38.0 mm
