TSP01-08A Multi-Channel Independent Control Split-Type Syringe Pump

Overview

The TSP01-08A is a precision multi-channel syringe pump system designed for demanding laboratory applications requiring independent control of up to 8 channels. This split-type design features touchscreen control or external control capability, offering maximum flexibility for complex fluid handling protocols. With a maximum stroke of 90mm and rated linear thrust ≥16kgf, this system delivers reliable performance across a wide range of research applications.

Key Features

The pump operates through a microprocessor-controlled 32-subdivision stepper motor driving a screw mechanism connected via synchronous belt, achieving exceptional precision with 0.3125μm per micro-step advancement. The system supports multiple operating modes including infusion, withdrawal, infusion-then-withdrawal, withdrawal-then-infusion, and continuous injection modes. Compatible with syringes ranging from 10μL to 60mL, the pump accommodates diverse experimental requirements. The linear velocity range spans from 3μm/min to 130mm/min, providing ultra-precise flow control with linear thrust exceeding 90N.

Applications

This multi-channel syringe pump is ideal for microfluidics research, drug delivery studies, perfusion experiments, and automated sample preparation. The independent channel control makes it particularly valuable for parallel processing applications, cell culture perfusion, and multi-reagent injection protocols. The precision and reliability make it suitable for pharmaceutical research, biotechnology applications, and analytical chemistry where accurate fluid delivery is critical.
