2-Channel Precision Syringe Pump
Dual-channel precision syringe pump accepting 50 µl to 200 ml syringes, with 0.107 µl micro-step resolution and 3.2-inch LCD touchscreen for microfluidics, droplet generation, and analytical chemistry workflows.
| Number of Channels | 2 |
| Automation Level | semi-automated |
| Syringe Compatibility | 50 µl to 200 ml |
| Resolution | 0.107 µl per micro-step (10 ml syringe) |
| Maximum Linear Speed | 65 mm/min |
| Minimum Linear Speed | 1 mm/min |
The 2-Channel Precision Syringe Pump delivers controlled dual-channel fluid dispensing for microfluidics, droplet generation, and analytical chemistry applications. Two independent syringe channels operate simultaneously, supporting protocols that require accurate flow rates and reproducible delivery volumes across extended experimental runs.
The pump accepts syringes from 50 µl to 200 ml, with micro-step resolution of 0.107 µl (using a 10 ml syringe). Linear speed range spans 1–65 mm/min with over 30 kgf of thrust, providing reliable displacement even with viscous fluids. A 3.2-inch LCD touchscreen interface allows direct parameter entry — syringe model selection from a built-in list or manual ID input, flow rate configuration across six units (µl/s, µl/min, µl/hr, ml/s, ml/min, ml/hr), and target volume setting with automatic stop.
The system supports both infusion and withdrawal modes, with power-interruption recovery that restores previous parameters on restart. Operates on DC 24V power in environments from 5–40°C.
How It Works
The precision syringe pump operates through controlled mechanical displacement of syringe plungers driven by stepper motor assemblies. Each channel contains an independent drive mechanism that advances the syringe plunger at programmed rates, creating positive displacement flow with minimal pulsation.
Flow rate accuracy depends on the precise mechanical displacement of the syringe volume combined with the temporal control of the drive mechanism. The system maintains consistent delivery by eliminating pressure-dependent flow variations common in peristaltic systems, instead relying on direct volumetric displacement.
Dual-channel operation allows simultaneous control of two fluid streams with independent flow rates, enabling mixing ratios, droplet generation, and multi-inlet experimental configurations. Each channel operates independently while sharing common control electronics and user interface.
Features & Benefits
Number of Channels
- 2
Automation Level
- semi-automated
Syringe Compatibility
- 50 µl to 200 ml
Resolution
- 0.107 µl per micro-step (10 ml syringe)
Maximum Linear Speed
- 65 mm/min
Minimum Linear Speed
- 1 mm/min
Linear Thrust
- >30 kgf
Display
- 3.2-inch LCD touchscreen
Input Voltage
- DC 24V
Operating Temperature
- 5–40°C
Operating Humidity
- <80% RH
Working Modes
- Infusion
- Withdrawal
Brand
- ConductScience
Weight
- 3.0 lbs
Dimensions
- L: 300.0 in
- W: 130.0 in
- H: 225.0 in
Comparison Guide
| Feature | This Product | Typical Alternative | Advantage |
|---|---|---|---|
| Number of Channels | 2 independent channels | Single-channel models are common in basic applications | Enables simultaneous multi-fluid experiments and mixing protocols without multiple pump units |
| Application Versatility | Droplet generation, mixing, two-inlet experiments | Basic models often limited to simple dispensing | Supports diverse experimental protocols from microfluidics to analytical chemistry |
| Pump Mechanism | Precision syringe-based displacement | Peristaltic systems common in general pumping | Provides superior flow accuracy and minimal pulsation for precise applications |
| Compact Design | 250mm × 200mm × 120mm footprint | Larger benchtop models typical for dual-channel systems | Maximizes bench space efficiency while maintaining dual-channel capability |
This 2-channel precision syringe pump combines compact design with dual-fluid capability, supporting diverse applications from droplet generation to analytical mixing. The precision syringe mechanism provides accurate volumetric control for protocols requiring minimal flow pulsation and consistent delivery.
Practical Tips
Verify flow rates gravimetrically using analytical balances for each channel before critical experiments.
Why: Ensures accurate delivery volumes for quantitative analytical procedures.
Clean syringe assemblies with appropriate solvents after each use to prevent contamination.
Why: Maintains dispensing accuracy and prevents cross-contamination between experiments.
Prime both channels thoroughly to eliminate air bubbles before starting experiments.
Why: Air bubbles can cause flow irregularities and affect droplet generation consistency.
Use appropriate syringe sizes for your required flow rate range and total volume needs.
Why: Proper syringe selection optimizes flow accuracy and experimental duration.
Check for leaks at all connection points if flow rates become inconsistent.
Why: Loose connections reduce system pressure and compromise volumetric accuracy.
Monitor and record environmental temperature as it can affect fluid viscosity and flow characteristics.
Why: Temperature variations impact fluid properties and can introduce systematic errors in delivery volumes.
Setup Guide
What’s in the Box
- 2-Channel Precision Syringe Pump main unit
- Power adapter (typical)
- User manual and operating instructions (typical)
- Basic tubing set (typical)
- Calibration certificate (typical)
Warranty
ConductScience provides a standard one-year manufacturer warranty covering defects in materials and workmanship. Technical support is available for setup, operation, and troubleshooting assistance.
Compliance
References
Background reading relevant to this product:
What syringe sizes are compatible with this pump system?
Consult product datasheet for specific syringe compatibility and mounting specifications.
Can the two channels operate at different flow rates simultaneously?
Yes, each channel operates independently with separate flow rate control for different experimental requirements.
What is the minimum achievable flow rate for precise dispensing?
Minimum flow rates depend on syringe size and drive mechanism specifications - consult technical documentation.
How is flow rate accuracy maintained during extended runs?
Precision syringe mechanisms provide consistent volumetric displacement independent of backpressure variations.
What maintenance procedures are required for optimal performance?
Regular cleaning of syringe assemblies and periodic calibration verification maintain dispensing accuracy.
Can this pump handle viscous solutions or only aqueous samples?
Syringe-based systems can handle various fluid viscosities - consult specifications for viscosity limits.
What control interface options are available for integration?
Consult product specifications for available control interfaces and communication protocols.
Is a battery included with the syringe pump for the LCD display?
The battery for the LCD display is not included with shipment. It is a common, inexpensive battery that can be purchased locally at most electronics or hardware stores.
What flow rate units are available?
Six flow rate units are available: µl/s, µl/min, µl/hr, ml/s, ml/min, and ml/hr. You can select the appropriate unit for your application during parameter setup.
Does the pump recover from power interruptions?
Yes. If power is interrupted during operation, the pump will resume with the previous parameters when power is restored.
