3D Electron USB LCD Screen Digital Video Stereo Microscope Intergrated Measuring Software Camera & LED Illuminator
Digital stereo microscope system with 17X-110X magnification, integrated 5MP camera, and measurement software for quantitative morphometric analysis.
| Automation Level | semi-automated |
| Product Type | Microscope |
| Microscope Type | Stereo / Dissecting |
| Application | Assembly & Rework, Sample Preparation |
| Skill Level | Intermediate |
| Brand | ConductScience |
The 3D Electron USB LCD Screen Digital Video Stereo Microscope combines traditional stereo microscopy with integrated digital imaging and measurement capabilities for quantitative analysis applications. The system features a 0.7X-4.5X stereo zoom objective with 6.4:1 zoom ratio, providing 17X-110X total magnification when combined with the 11.6-inch IPS display. The 360° rotation capability with 45° viewing angle lens enables comprehensive specimen examination from multiple perspectives.
The integrated 5-megapixel camera captures high-resolution images at 60fps real-time display and 45fps recording capability, while built-in measurement software provides dimensional analysis tools including point, line, angle, and circular measurements. The system connects via dual USB 2.0 interfaces and HDMI output, enabling direct storage to USB devices and external display connectivity. This configuration supports applications requiring both visual inspection and quantitative morphometric analysis across multiple research and quality control environments.
How It Works
The system employs stereo microscopy principles with dual optical paths to provide three-dimensional visualization of specimens. The 0.7X-4.5X zoom objective creates magnified images that are captured by a 5-megapixel imaging sensor operating at 60fps for real-time display. The stereo configuration with adjustable viewing angles enables depth perception and comprehensive specimen examination from multiple orientations.
Digital image processing converts optical information to electronic signals displayed on the 11.6-inch IPS screen at 1920×1080 resolution. The integrated measurement software utilizes pixel-to-distance calibration to provide quantitative dimensional analysis. Users can perform various measurements including linear distances, angles, and circular parameters directly on captured images.
The 360° rotation capability combined with 45° viewing angle adjustment allows complete specimen examination without physical repositioning. Image and video data are stored via USB interfaces, while HDMI output enables connection to external displays or projection systems for collaborative analysis.
Features & Benefits
Automation Level
- semi-automated
Product Type
- Microscope
Microscope Type
- Stereo / Dissecting
Application
- Assembly & Rework
- Sample Preparation
Skill Level
- Intermediate
Brand
- ConductScience
Research Domain
- Analytical Chemistry
- Environmental Monitoring
- Food Science
- Industrial Hygiene
- Materials Science
- Microbiology
- Pharmaceutical QC
Weight
- 1.9 kg
Dimensions
- L: 4.9 mm
- W: 6.6 mm
- H: 6.6 mm
Comparison Guide
| Feature | This Product | Typical Alternative | Advantage |
|---|---|---|---|
| Magnification Range | 17X-110X with 6.4:1 zoom ratio | Entry-level systems often provide narrower zoom ranges or require manual objective changes | Wide magnification range eliminates need for multiple objectives during analysis workflows |
| Display Integration | 11.6-inch IPS screen with 1920×1080 resolution | Many systems require separate monitors or computer connections | Integrated display reduces setup complexity and provides immediate high-resolution viewing |
| 3D Visualization Capability | 360° rotation with 45° viewing angle lens | Standard microscopes offer fixed viewing perspectives | Complete specimen examination from all angles without physical repositioning |
| Measurement Software Integration | Built-in measurement tools for point, line, angle, and circular analysis | Separate measurement software often required | Integrated measurement capabilities streamline quantitative analysis workflows |
| Recording Frame Rate | 60fps real-time, 45fps recording | Lower frame rates common in budget systems | High frame rates enable smooth visualization of dynamic processes and quality video documentation |
This system combines stereo microscopy with integrated digital imaging, 3D visualization capabilities, and comprehensive measurement software in a single unit. The 360° rotation mechanism and high-resolution display provide enhanced specimen examination compared to traditional fixed-perspective microscopy systems.
Practical Tips
Perform measurement calibration at each magnification level using certified dimensional standards before conducting quantitative analysis.
Why: Magnification changes affect pixel-to-distance ratios and require separate calibration for accurate measurements.
Clean optical surfaces with appropriate lens cleaning materials and store calibration standards in protective containers.
Why: Clean optics ensure optimal image quality and protected standards maintain calibration accuracy over time.
Use consistent illumination settings and specimen positioning for reproducible measurements across different analysis sessions.
Why: Standardized conditions reduce measurement variability and improve data reliability in quantitative studies.
Capture multiple images from different angles using the 360° rotation capability for comprehensive specimen documentation.
Why: Multiple perspectives provide complete morphological characterization and reduce the risk of missing important features.
If image quality degrades, check LED illumination intensity and optical surface cleanliness before adjusting camera parameters.
Why: Most image quality issues stem from illumination or optical contamination rather than electronic settings.
Ensure specimens are properly secured on the stage before using rotation functions to prevent sample damage or loss.
Why: Rotating specimens can shift position if not properly stabilized, potentially causing sample loss or damage.
Save measurement templates for repeated analysis procedures to ensure consistent methodology across samples.
Why: Standardized measurement protocols improve reproducibility and reduce analysis time for routine procedures.
Setup Guide
What’s in the Box
- 3D digital stereo microscope main unit
- 11.6-inch IPS LCD display screen
- LED illumination system
- Dual USB 2.0 cables
- HDMI cable
- Power adapter and cables
- Measurement calibration standard (typical)
- User manual and software installation guide
- Mouse for OSD operation
Compliance
References
Background reading relevant to this product:
Warranty & ConductCare
ConductScience provides a 1-year manufacturer warranty covering defects in materials and workmanship, with technical support for software configuration and measurement calibration procedures.
What is the measurement accuracy and calibration procedure for dimensional analysis?
Measurement accuracy depends on proper calibration using certified standards at each magnification level. The software requires pixel-to-distance calibration with known reference dimensions before quantitative measurements can be performed.
Can the system handle specimens with significant height variation?
The stereo configuration provides depth perception and the 360° rotation with 45° viewing angle allows examination of specimens with complex topography. However, extreme height variations may require focus adjustment during examination.
What file formats are supported for image and video storage?
Consult product datasheet for specific file format compatibility. The system supports USB storage for direct file transfer and HDMI output for external recording devices.
How does the 3D capability enhance measurement compared to traditional microscopy?
The stereo optics with 360° rotation enables three-dimensional visualization and measurement from multiple angles, providing more comprehensive dimensional analysis than single-perspective imaging.
What is the working distance and stage capacity for specimen accommodation?
Consult product specifications for exact working distance and stage dimensions. The system is designed for tabletop specimens that fit within the optical working distance of the stereo objective.
Can multiple users view specimens simultaneously during analysis?
The 11.6-inch display and HDMI output capability allow multiple observers to view specimens simultaneously, supporting collaborative analysis and teaching applications.
What maintenance is required for the LED illumination and optical systems?
LED illuminators typically require minimal maintenance due to long operational life. Optical surfaces should be cleaned periodically with appropriate lens cleaning materials to maintain image quality.
