High-Precision Syringe Pump RS485 Control

Overview

The W09-02R Syringe Pump is a high-precision, high-force injection system designed for demanding laboratory applications. With its compact footprint of 259mm×99.4mm×133mm and powerful 90N linear force capability, this pump delivers exceptional accuracy and reliability for volumes ranging from 10μL to 60mL syringes. The system features advanced RS485 communication with Modbus RTU protocol, enabling seamless integration into automated laboratory workflows.

Key Features

Exceptional precision is achieved through 0.3125μm stroke resolution and control accuracy within ±0.35% (10% F'S), with repeatability accuracy reaching ±0.03% F'S. The pump supports flow rates from 924pL/min to 136.235mL/min, accommodating diverse experimental requirements. Seven operational modes including infusion, withdrawal, sequential operations, and continuous modes provide maximum flexibility. The RS485 interface allows up to 32 units to be controlled simultaneously, while status outputs for start/stop, direction, and blockage alarm ensure reliable operation monitoring. Power failure memory and quick advance/retreat functions enhance operational convenience.

Applications

Ideal for microfluidics research, drug delivery studies, cell culture perfusion, analytical chemistry sample preparation, and automated liquid handling systems. The pump's high precision makes it particularly suitable for applications requiring accurate delivery of small volumes, such as pharmaceutical research, biological assays, and chemical synthesis protocols. The multi-unit control capability enables complex experimental setups requiring synchronized fluid delivery across multiple channels.
