Industrial Syringe Pump Controller
The SP60-C1A Industrial Syringe Pump Controller provides precise single-channel control for automated liquid handling with three operational modes and intuitive touchscreen operation. Features external control I/O, power-off memory, and compact IP...
Overview
The SP60-C1A Industrial Syringe Pump Controller is a precision control system designed for automated liquid handling in laboratory and industrial applications. This single-channel controller enables seamless operation of industrial syringe pumps for pipetting, dispensing, and mixing operations. With its intuitive 5-inch touchscreen interface and comprehensive I/O capabilities, this controller provides reliable automation for fluid handling workflows.
Key Features
The controller features three operational modes: continuous, dispensing, and aspiration, providing flexibility for diverse liquid handling protocols. The full touchscreen operation ensures user-friendly parameter configuration and monitoring. Built-in power-off memory retention preserves critical settings and protocols. External control capabilities include active input and passive output signals, enabling integration with automated systems. The compact IP31-rated housing ensures durability in laboratory environments while maintaining a small footprint of 120×188×67.5mm.
Applications
Ideal for automated sample preparation, reagent dispensing, and chemical synthesis applications. Commonly used in pharmaceutical research, analytical chemistry, and biotechnology laboratories requiring precise fluid control. The dual connection interface design allows for future expansion while maintaining current single-pump operation. Suitable for integration into larger automated laboratory systems through external control signals.
Weight
- 29.98 kg
Dimensions
- L: 30.0 mm
- W: 20.0 mm
- H: 15.0 mm
Specifications
| Model | SP60-C1A |
| Working Modes | Continuous mode, Dispensing mode, Aspiration mode |
| Execution Units | 1 |
| Display | 5-inch touchscreen |
| Operation | Full touchscreen operation |
| Power-off Memory | Yes |
| External Control Signal | Active input, Passive output |
| Power Supply | DC24V, 36W |
| Operating Temperature | 0~40°C |
| Relative Humidity | <80% |
| Protection Rating | IP31 |
| Dimensions | 120×188×67.5mm |
| Weight | 1kg |
Frequently Asked Questions
What power supply is required for this controller?
The controller requires DC 24V power supply with 36W power consumption.
Can this controller operate multiple syringe pumps simultaneously?
No, this is a single-channel controller designed to control one industrial syringe pump at a time, though it has connection interfaces for future expansion.
What environmental conditions are suitable for operation?
The controller operates in temperatures from 0-40°C with relative humidity below 80%, and has IP31 protection rating for standard laboratory environments.
