Soil Three-Parameter Tester
Measure soil moisture (0–100%), temperature (−5–50 °C), and EC (0–200 mS m⁻¹) simultaneously.
IP65, 2.5 s response, 2,100-point data logger included.
Louise Corscadden, PhD
Director of Science · ConductScience
Ask Louise about Soil Three-Parameter Tester fit, setup, configuration, or quote prep.
Already working with us? Sign in to connect this with My Scientist.
Key Specifications
Full details →- Soil Moisture Range
- 0–100%
- Soil Moisture Accuracy
- ±3%
- Soil Moisture Resolution
- 0.1%
- Soil Temperature Range
- -5 to 50 °C
- Soil Temperature Accuracy
- ±1.5 °C
- Soil Temperature Resolution
- 0.1 °C
The Soil Three-Parameter Tester is a portable field instrument that simultaneously measures soil volumetric moisture content, temperature, and electrical conductivity (EC) in a single insertion. Designed for outdoor use, it delivers three critical soil health indicators in one reading—eliminating the need for separate probes and reducing disturbance to the sampling site.
A standout capability of this sensor is its ability to report soil electrical conductivity (ECP) alongside moisture and temperature readings, giving researchers and agronomists a richer picture of ion concentration and salinity conditions. With a moisture range of 0–100%, a temperature range of −5 to 50 °C, and an EC range of 0–200 mS m⁻¹, the instrument spans the conditions encountered in most horticultural and research plots.
Operating at 20 MHz, the sensor responds in 2.5 seconds and connects via a standard 2 m cable to a reader that can store up to 2,100 data points for later transfer to analysis software. The IP65-rated waterproof interface makes it suitable for wet soil conditions and outdoor field campaigns.
Typical applications include horticultural trials, greenhouse substrate monitoring, field-crop irrigation management, and soil science research where co-located moisture, temperature, and conductivity data are required at the same soil volume.
Soil Moisture Range
- 0–100%
Soil Moisture Accuracy
- ±3%
Soil Moisture Resolution
- 0.1%
Soil Temperature Range
- -5 to 50 °C
Soil Temperature Accuracy
- ±1.5 °C
Soil Temperature Resolution
- 0.1 °C
EC Range
- 0–200 mS m⁻¹
EC Accuracy
- ±10 mS m⁻¹
EC Resolution
- 0.1 mS m⁻¹
Working Frequency
- 20 MHz
Working Voltage
- 6–10 V DC
Response Time
- 2.5 s
Data Storage (Reader)
- 2,100 readings
Standard Cable Length
- 2 m
Probe Dimensions
- Outer probes: 3 mm diameter × 68 mm length; Middle probe: 5 mm × 60 mm
IP Rating
- IP65 (waterproof interface)
Operating Temperature (Instrument)
- 0–50 °C
Included Items
- Sensor, reader, battery, communication cable, software, manual and portable box
What three parameters does this sensor measure simultaneously?
Each insertion returns soil volumetric moisture content (0–100%), soil temperature (−5 to 50 °C), and soil electrical conductivity (0–200 mS m⁻¹). The simultaneous EC reading also allows you to derive the electrolytic conductivity of the soil pore water (ECP) when moisture data are available.
What accuracy can I expect for each measurement?
The sensor is specified at ±1.5 °C for temperature, ±10 mS m⁻¹ for EC, and ±3% for soil moisture. Resolution is 0.1 °C for temperature, 0.1 mS m⁻¹ for EC, and 0.1% for moisture.
What is included in the package?
The kit includes the sensor itself, a battery, a communication cable, data-logging software, a user manual, and a portable carrying case. A standard 2 m cable connects the probe to the data reader.
How much data can I store in the field, and how do I retrieve it?
The accompanying reader stores up to 2,100 readings onboard. Data are transferred to a computer via the communication cable and the included software for further analysis.
Is the sensor suitable for wet or rainy field conditions?
Yes. The sensor interface carries an IP65 waterproof rating, so it is protected against water jets and the wet soil conditions typical of irrigation trials or post-rainfall sampling. The working environment temperature range is 0–50 °C.
