ABBE Digital Refractometer
High-precision digital Abbe refractometer with ±0.00001 nD resolution, 8 test modes, and touchscreen interface for accurate refractive index and Brix measurements.
Louise Corscadden, PhD
Director of Science · ConductScience
Ask Louise about ABBE Digital Refractometer fit, setup, configuration, or quote prep.
Already working with us? Sign in to connect this with My Scientist.
Key Specifications
Full details →- Model fit
- Configured during quote
- SKU family
- BIO-0470
- Shipping box
- 11.0 × 34.0 × 20.0 cm
- Ordering
- Online checkout and quote request available
- Category
- Refractometers
- Build notes
- Confirm accessories, station layout, and support needs before purchase
The ABBE Digital Refractometer is a high-precision optical instrument designed for accurate refractive index and Brix measurements in research and analytical laboratories. This digital refractometer combines traditional Abbe measurement principles with modern touchscreen interface and data management capabilities, offering refractive index measurements from 1.30000 to 1.70000 nD with ±0.00001 nD resolution.
The instrument features eight test modes, temperature-compensated measurements across 10-60°C, and multiple data interfaces including RS232, USB, and U disk storage. The hard glass prism construction ensures durability and measurement stability, while the 7-inch LCD touchscreen provides intuitive operation and real-time data display. Temperature accuracy of ±0.1°C and refractive index accuracy of ±0.0002 nD support demanding analytical protocols requiring precise optical characterization.
How It Works
The Abbe refractometer operates on the principle of critical angle measurement, where light passing through a sample creates a distinct boundary between light and dark regions on the detector. When light travels from a denser medium (sample) to a less dense medium (air), total internal reflection occurs at angles greater than the critical angle, which is directly related to the sample's refractive index.
The instrument illuminates the sample placed between the measuring prism and auxiliary prism with monochromatic light. The critical angle boundary is detected by the optical system and converted to refractive index values through calibrated algorithms. Temperature compensation is automatically applied using the integrated temperature sensor, as refractive index varies predictably with temperature for most materials.
Digital processing converts the optical measurements to both refractive index (nD) and Brix percentage scales simultaneously. The eight test modes allow optimization for different sample types and measurement requirements, while the touchscreen interface provides real-time display of results with specified precision.
Features & Benefits
Research record
Use these values in methods sections and data records.
- Device type
- Refractometer
NCIT:C78809
This ID comes from the NCI Thesaurus (NCIT).
Download the source data for this record as a JSON-LD file
Methods section wording
refractometer (ConductScience, Skokie, IL, USA; cat. no. BIO-0470)
Automation Level
- semi-automated
Measuring Range
- 1.30000~1.70000nD, Brix: 0~100%
Measuring Resolution
- ±0.00001nD, Brix: ±0.01%
Measuring Accuracy
- ±0.0002nD, Brix: ±0.1%
Test Mode
- 8
Weight
- 9kg
Temperature Resolution
- 0.1℃
Temperature Accuracy
- 0.1℃
Interface
- RS232, USB, U disk
Prism
- Hard glass
External Size(W*D*H)
- 340*200*110mm
Package Size(W*D*H)
- 500*330*220mm
Brand
- ConductScience
Research Domain
- Analytical Chemistry
- Environmental Monitoring
- Food Science
- Industrial Hygiene
- Materials Science
- Pharmaceutical QC
Temperature Range
- 10~60℃
Display Type
- 7 LCD touch screen
Power/Voltage
- AC110/220V, 50/60Hz
Shipping weight
- 9.0 lb
Shipping box
- L: 11.0 cm
- W: 34.0 cm
- H: 20.0 cm
| Feature | This Product | Typical Alternative | Advantage |
|---|---|---|---|
| Refractive Index Resolution | ±0.00001 nD | Entry-level models often provide ±0.0001 nD resolution | Higher resolution enables detection of smaller concentration differences in analytical applications. |
| Test Modes | 8 test modes | Basic models typically offer 2-3 measurement modes | Multiple test modes optimize measurements for different sample types without recalibration. |
| Display Interface | 7-inch LCD touchscreen | Many instruments use small digital displays or eyepiece viewing | Large touchscreen interface improves usability and allows real-time data visualization. |
| Temperature Range | 10-60°C compensation | Standard models often limit to 15-40°C | Extended temperature range supports diverse analytical protocols and sample conditions. |
| Data Connectivity | RS232, USB, and U disk | Basic models may offer only USB or no data export | Multiple interface options ensure compatibility with various laboratory data systems. |
| Measurement Accuracy | ±0.0002 nD | Standard instruments typically achieve ±0.0005 nD | Higher accuracy supports critical analytical measurements requiring exceptional precision. |
This digital Abbe refractometer combines high-resolution measurement capabilities with comprehensive data management features. The touchscreen interface and multiple connectivity options distinguish it from traditional analog instruments, while the eight test modes provide measurement optimization capabilities typically found in more specialized systems.
Practical Tips
Perform calibration verification using distilled water at precisely 20°C as a daily reference check.
Why: Water provides a stable, reproducible reference standard for verifying measurement accuracy.
Clean prism surfaces immediately after each measurement using appropriate solvents and lint-free tissues.
Why: Sample residue can affect subsequent measurements and potentially damage the prism surface over time.
Allow samples to equilibrate to room temperature before measurement, especially when transitioning between different sample types.
Why: Temperature gradients within the sample can create measurement instability and reduce accuracy.
Record multiple measurements and calculate mean values for critical analytical determinations.
Why: Replicate measurements improve precision and help identify potential sampling or technique errors.
If readings appear unstable, check for air bubbles in the sample or inadequate prism surface coverage.
Why: Air-sample interfaces create optical discontinuities that interfere with critical angle detection.
Use appropriate personal protective equipment when handling corrosive or toxic samples.
Why: Sample contact with skin or eyes poses potential health risks depending on chemical properties.
Store the instrument with prism surfaces clean and dry when not in use for extended periods.
Why: Residual moisture or sample contamination can lead to measurement drift and potential corrosion.
Setup Guide
What’s in the Box
- ABBE Digital Refractometer main unit
- AC power adapter (110/220V)
- USB cable
- Calibration certificate
- User manual and software documentation
- Cleaning accessories (typical)
- Sample applicator (typical)
Warranty
ConductScience provides a standard one-year manufacturer warranty covering defects in materials and workmanship. Technical support includes calibration guidance and operational assistance.
Compliance
What calibration standards are recommended for verification?
Use certified refractive index standards covering your measurement range. Distilled water (nD = 1.33250 at 20°C) provides a common reference point, while sucrose solutions offer Brix scale verification.
How much sample volume is required per measurement?
Approximately 2-3 drops are sufficient to cover the prism surface. Excessive sample volume does not improve accuracy and may complicate cleaning procedures.
Can the instrument measure turbid or colored samples?
Sample clarity affects measurement accuracy. Filter turbid samples when possible, as suspended particles scatter light and interfere with critical angle detection.
What data export formats are supported?
Data can be exported via USB, RS232 interface, or U disk storage. Consult product datasheet for specific file formats and software compatibility requirements.
How frequently should calibration verification be performed?
Daily verification with reference standards is recommended for critical analytical work. Weekly verification may be sufficient for routine quality control applications.
What cleaning solvents are compatible with the prism?
Use distilled water, ethanol, or isopropanol for routine cleaning. Avoid strong acids or bases that may damage the hard glass prism surface.
Can measurements be performed at elevated temperatures?
The instrument compensates for temperatures from 10-60°C. Sample temperature should equilibrate with the prism before measurement for optimal accuracy.
