Crossing Latency
Time to traverse the beam from start to goal platform
ConductVision · Behavioral Analysis
Balance Beam Test
Evaluate balance, coordination, and motor control on a narrow beam.
RodentMotor CoordinationAuto Export
ConductVision / Balance Beam Test
Recording / Trial 3subject tracked
Crossing Time5.8s
Foot Slips2
Beam Score1.5
Key Parameters
Metrics automatically extracted by ConductVision.
Foot Slip Count
Number of hind- and forepaw slips detected per crossing
Foot Slip Rate
Slips per unit distance — primary coordination index
Traversal Speed
Average movement speed across the beam surface
Fall Events
Number of falls off the beam into the safety hammock
Beam Score
Composite motor score on Metz (0–2) or Luong (1–7) grading scale
+ 8 more parameters trackedShow allHide
Hindlimb Slip Frequency
Slips from each hindpaw scored independently (left vs. right)
Forelimb Slip Frequency
Slips from each forepaw scored independently (left vs. right)
Latency to Initiate
Time from placement on beam to first forward step
Stall Duration
Total time spent paused or hesitating mid-beam
Hesitation Count
Number of distinct pause episodes during a single crossing
Total Step Count
Number of individual limb placements per crossing
Hindlimb Placement
Position scoring — plantar on beam, plantar sandwich, or thigh grip
Trial-to-Trial Improvement
Latency and slip reduction across successive trials within a session
What is the Balance Beam Test?
The Balance Beam test evaluates balance, coordination, and motor control by measuring how rodents traverse a narrow elevated beam. Subjects walk from a start platform to a dark goal box at the opposite end, motivated by the aversion to the exposed, elevated surface. Beam width (6–48 mm) can be varied to modulate task difficulty and reveal graded deficits in cerebellar, motor cortex, and basal ganglia function.
ConductVision automates scoring using AI-based body and limb tracking, detecting foot slips with frame-level precision and evaluating paw placement accuracy. The system distinguishes hindlimb from forelimb slips, quantifies hesitation behavior, and applies standardized grading scales (Metz or Luong) — eliminating the subjectivity and low throughput of manual scoring.
Protocol Parameters
| Parameter | Description | Default |
|---|---|---|
| Beam Length (Mouse) | Length of the traversable beam surface | 100 cm |
| Beam Length (Rat) | Length of the traversable beam surface | 125 cm |
| Beam Height | Elevation above the floor or table top | 50 cm |
| Beam Widths | Available widths to modulate difficulty | 6, 12, 24, 48 mm |
| Goal Box Size (Mouse) | Darkened escape box at the end of the beam | 20 × 20 × 20 cm |
| Goal Box Size (Rat) | Darkened escape box at the end of the beam | 25 × 25 × 25 cm |
| Safety Hammock | Nylon hammock below the beam to catch falls | ~7.5 cm below beam |
| Training Days | Consecutive days of habituation before test day | 2 days |
| Training Trials/Day | Guided trials per session during training | 6 (3 × 12 mm + 3 × 6 mm) |
| Rest Between Widths | Inter-trial interval when switching beam width | 10 min |
| Pre-Test Acclimation | Room acclimation before first trial | ≥ 60 min |
Interpreting Results
↑
Increased Crossing Latency
Motor coordination deficit — longer traverse time seen in stroke, TBI, and Parkinson's disease models.
↑
Elevated Hindlimb Foot Slips
Hindlimb-specific motor impairment — the most sensitive indicator of cerebellar and corticospinal tract dysfunction.
↑
Increased Fall Events
Severe motor deficit — animal cannot maintain balance, common with large cerebellar lesions or advanced neurodegeneration.
↑
Prolonged Hesitation / Stalling
Anxiety or proprioceptive uncertainty on the beam — hesitation adds 0.88–2.24 s to crossing time and can confound motor scoring.
↓
Reduced Beam Score
Lower composite score on Metz or Luong scale indicates progressive loss of coordinated locomotion.
↓
Impaired Trial-to-Trial Improvement
Failure to improve across successive trials suggests motor learning deficit in addition to coordination loss.
Research Applications
Neurological Injury & Recovery
- Stroke recovery — more sensitive than rotarod for detecting fine motor deficits post-ischemia
- Traumatic brain injury — longitudinal tracking of motor recovery trajectories
- Spinal cord injury — hindlimb-specific scoring with 0–7 point SCI-adapted scale
Neurodegenerative Disease
- Parkinson's disease — dopaminergic depletion models with progressive coordination loss
- Huntington's disease — early motor phenotyping before overt chorea
- Cerebellar ataxia — beam width titration reveals graded ataxic severity
Pharmacology & Aging
- Drug screening — neuroprotective and neuroregenerative compound evaluation
- Age-related motor decline — longitudinal phenotyping across the lifespan
- Sedation and motor side-effect profiling for CNS-active compounds
