Split Type Shakers

• Features
• Introduction
• Product Features
• Key Functions

Parameters Comparison for Models

Model	SB-DS-3D100 Multi-function Shaker (Horizontal + Pendulum+ 3D)	SB-DS-2H200 Shaker (Horizontal) SB-DS-2S100 Shaker (Pendulum)	SB-SYC-P200 Digital Display Horizontal Shaker SB-SYC-Z100 Digital Display Pendulum Shaker	SB-SYC-FP200 Split-type, Horizontal Shaker SB-SYC-FZ100 Split-type, Pendulum
Speed range	Horizontal: 5-100 rpm Pendulum: 5-100 rpm.	Horizontal：5-200 rpm Pendulum：5-100 rpm	Horizontal： 0-200 rpm Pendulum：0-100 rpm	Horizontal： 0-200 rpm Pendulum：0-100 rpm
Swing radius and swing amplitude	Horizontal model swing radius：15mm Pendulum swing angle：10°	Horizontal model swing radius：15mm Pendulum swing angle：10°	Horizontal model swing radius：10mm Pendulum swing angle：20°	Horizontal model swing radius：10mm Pendulum swing angle：20°
3D operation	Speed of the composite mode in 3D mode 5-100 rpm Relative running speed in 3D composite operation mode： 1%-100%	N/A	N/A	N/A
Automatic leveling function	Yes	Yes	Yes	Yes
Timer range	0-999h / 59min	0-999h / 59min	0-999h / 59min	0-999h / 59min
Digital display	Digital display of time and speed	Digital display of time and speed	Digital display of time and speed	Digital display of time and speed
Max loading capacity	5kg	5kg	2.5kg	2.0kg
Motor parameters	Stepper motor	Stepper motor	Stepper motor	Stepper motor
Control mode	Program-controlled chip	Program-controlled chip	Program-controlled chip	Program-controlled chip
Tray size	338*308mm	338*308mm	317*245mm	317*245mm
Buzzer reminder	Yes	Yes	Yes	Yes
Power	35W	20W	20W	20W
Fuse	250V,3A	250V,3A	N/A	N/A
Controller size	35mm	35mm	35mm	35mm
Display size	740*420mm	740*420mm	N/A	N/A
Dimensions	380*330*180 mm	380*330*148 mm 380*330*173 mm	317*245*130mm 317*245*139mm	317*245*134mm 317*245*143mm
Net Weight	9.5kg	7.6kg/8.5kg	4.5kg	4.5kg

Introduction

Shakers are commonly used in Western experiments such as blocking of blotting membranes, antibody incubation, washing, fixation, staining, and destaining of electrophoretic gels; they can also be used for shaking liquids in various centrifuge tubes, multi-well plates, petri dishes, and culture bottles. Mix well.

Product Features

Horizontal Shaker [Split Type] SB-SYC-FP200

1.Split design, with a flat cable connecting the controller, allowing the controller to be placed in a refrigerator, incubator, or chromatography cabinet. 2.Internal waterproof treatment, suitable for high humidity, low temperature, and other environments. 3.Equipped with a stepper motor for accurate speed control and durability. 4.Features a timer reminder function and power-off memory function.

Pendulum Shaker [Split Type] SB-SYC-FZ100

1. Small design, easy to move 2. Power-off memory, automatically continues to run after power-off 3. Waterproof, Resistant to high humidity and low temprature 4. Stepper Motor for accurate speed control and durability 4. Autoleveling at end of run avoid sample spillage

Key Functions of the Split type shaker

• Independent Settings: Allows separate control of speed and angle for each motion type.
• Versatile Use: Suitable for various sample types, from intense shaking to gentle rocking.
• Reliable Operation: Ensures stable performance with minimal vibration.
• Simple Mode Switching: Easy to switch between horizontal and pendulum modes.
