Introduction

Fast protein liquid chromatography (FPLC) is a type of liquid chromatography that provides high resolution by small-diameter stationary phases for protein characterization and separation. The technique features high loading capacity, biocompatible buffer systems, fast flow rates, and stationary phases for common chromatography modes (e.g., gel filtration, ion exchange, reversed phase, and affinity chromatography). The system enables reproducible separation by incorporating a high level of automation including samplers, gradient program control, and peak collection. FPLC allows the users to monitor several parameters at a time such as UV level, pH, and conductance and it allows for multiple columns to be run in tandem; therefore, minimizing the time needed to isolate pure protein. The method is applicable to proteins as well as other kinds of biological samples including oligonucleotides and plasmids.



Principle

In fast protein liquid chromatography, the solvent velocity is controlled by a microprocessor through a software interface to maintain the constant flow rate of the solvents. The mobile phase is an aqueous buffer, and the flow rate is kept constant by a positive-displacement pump while the buffer composition can be varied by drawing fluids from external reservoirs. The stationary phase is composed of beads, usually of cross-linked agarose, packed into a cylindrical column. The eluant is passed through the detectors to measure the salt concentration (by conductivity) and protein concentration (by absorbing ultraviolet light at a wavelength of 280nm).



Apparatus & Equiment

The FPLC system consists of a control unit, high-precision pumps, a column, detection system, and a fraction collector. The pump allows the fraction of each buffer entering the column to be continuously varied. The injection loop, a segment of tubing of known volume, is filled with the sample solution to be injected in the column. The sample loading is done by the injection valve which links the mixer and sample loop to the column. The FPLC column is a glass or plastic cylinder packed with beads of resin. It is mounted vertically with the buffer flowing downward from top to bottom. The eluant from the column passes through the flow cells for protein concentration measurements. The detector records the salt and protein concentration.



Protocol (Madadlou., Sullivan., & Sheehan., 2011)

Sample preparation

  1. Aspire Sephadex G-25 resin as a slurry in water into the column before packing.
  2. Equilibrate the column in 3-4 column volumes of buffer A (10 mM Tris-HCl, pH 7.0).
  3. Load the sample (50 mL) under gravity flow.
  4. Pass buffer A through the column and monitor the protein by measuring A280, and collect it as a single large peak.
  5. Measure the conductivity using the conductivity meter.

FPLC modes

Ion-exchange FPLC

  1. Prime the pumps A and B with filtered and degassed buffers A (10 mM Tris–HCl, pH 7.0.) and B (10 mM Tris–HCl, pH 7.0, 1 M NaCl), respectively.
  2. Set the pressure limits on both the pumps below the maximum for the column in use.
  3. Equilibrate the Mono Q column (1 mL volume) with 5 volumes of buffer A and 10 volumes of buffer B and then with 5 volumes of buffer A.
  4. Wash the sample loading loop with buffer A.
  5. Load the sample (0.5–10 mL) (approximately 1 mg/mL) and wash the column with buffer A. Collect the flow-through and evaluate for the protein of interest.

Note: If protein is not bound then replace the Mono Q column with the Mono S column.

  1. Regenerate the column by washing it with 10 volumes of buffer B, then with 5 volumes of buffer A.

Scouting FPLC methods

  1. Create gradients of shallowness by varying the concentration of buffer B at different time-points.
  2. Identify the column to which the protein binds and perform chromatography at different pH values using various buffer systems.

Gel-filtration FPLC

  1. Prime the pumps A and B with buffer C (50 mA/Tris-HCl, pH 7.0, 100 mM KCl) with no column in the system.
  2. Set the pressure limits on both P-500 pumps.
  3. Connect Superose 12, and operate the system at 0.5 mL/min flow rate for 90 minutes for column equilibration.
  4. Wash the sample loading loop with buffer C.
  5. Load 200 µL of the sample at the rate of 2 mg/mL.
  6. Monitor A280; collect peaks with the fraction collector and record the elution volume of peak.





Applications

Diagnosis of β-thalassemia (Tangvarasittichai., Tangvarasittichai., & Jermnim., 2009)

β-thalassemia is a genetic blood disorder in which hemoglobin production is reduced. For its diagnosis, quantitative hemoglobin A2 (HbA2) levels are used. High-performance liquid chromatography (HPLC), electrophoresis, and microcolumn chromatography are the conventional techniques for beta-thalassemia diagnosis. In the study, fast protein liquid chromatography (FPLC) method was established to measure HbA2 levels in the samples. The FPLC method, using a DEAE Sepharose, anion-exchange column chromatography technique was set up for diagnosis. The FPLC results were highly correlated (r = 0.985, P<0.001) with those of HPLC, cellulose acetate electrophoresis (r = 0.977), and microcolumn chromatography (r = 0.980). The method was found 100 percent sensitive and specific for β-thalassemia diagnosis. In addition, the technique was simple, rapid, cheaper, and reproducible.



Separation of plasma proteins in urine and cerebrospinal fluid (Cooper., Turner., Johns., Lindblom., & Britton., 1983)

Fast protein liquid chromatography (FPLC) with an anion-exchange column mode provides rapid separation and reproducible characterization of the plasma proteins in urine and cerebrospinal fluid (CSF). It just takes 1 hour for urine specimens and 45 minutes for CSF. The FPLC was used to identify the elution characteristics of 21 plasma proteins. The study has presented the applications of fast-protein liquid chromatography for the profiling of tubular proteinuria, isolation of urine proteins, and the evaluation of hemoglobin-derived products. FPLC has been found useful in clinical research for the rapid identification of protein profiles and micro-variability within a single protein.



Assessment of protein unfolding (Uversky., 1993)

Fast protein size-exclusion liquid chromatography (SEC-FPLC) was used to explore the solvent-induced unfolding of proteins. Six proteins were evaluated: two of them (sperm whale myoglobin and hen white lysozyme) and the other four proteins (bovine and human a-lactalbumin, bovine carbonic anhydrase B (BCAB), and 8-lactamase from Staphylococcus aureus). It was shown that the permeation properties of the Superose 12 columns are independent of temperature, pH, and denaturants. It was also indicated that protein molecules could only be in one of the two unfolding states with different compactness under denaturant effect. The results suggested that FPLC is one of the most direct approaches to establish the “all-or-none” mechanism to study the solvent-induced denaturation of globular proteins. The fast protein size-exclusion liquid chromatography (FPLC) does not shift the equilibrium between the unfolding states and therefore; could be used for qualitative and quantitative evaluation of protein denaturation.



Precautions
  • Use neutral pH to allow the assessment of both anions- and cation-exchange columns at the same pH.
  • Avoid pH extremes to prevent protein denaturation.
  • The FPLC procedure should be performed at 4°C for the purification of labile proteins.
  • To avoid NaCl precipitation, prime pumps with water to remove 20% ethanol.
  • Decreased flow rates should be used for improved resolution in gel-filtration chromatography.
  • Wash the system with water after the procedure.



Strengths and limitations
  • The fast-protein liquid chromatography is a simple and reproducible separation technique with efficient resolution.
  • The chromatography columns have longer lifetime because of the inert construction against the very high salt concentrations and corrosive liquids.
  • The FPLC supports a wide range of columns as the procedures are carried out under low pressure.
  • The wide flow range makes it a suitable technique for analytical and preparative chromatography.
  • The technique needs glass columns and cannot withstand high pressures.
  • The method is not sensitive to thermolabile proteins.



References
  1. A. Madadlou., S. O’Sullivan., & Sheehan., D. (2011). Fast protein liquid chromatography. Methods Mol Biol, 681, 439-47.
  2. E. Cooper., R. Turner., A. E. Johns., H. Lindblom., & Britton., J. V. (1983). Applications of fast protein liquid chromatography TM in the separation of plasma proteins in urine and cerebrospinal fluid. Clin Chem, 29(9), 1635-40.
  3. Tangvarasittichai., O. Tangvarasittichai., & Jermnim., N. (2009). Comparison of fast protein liquid chromatography (FPLC) with HPLC, electrophoresis & microcolumn chromatography techniques for the diagnosis of beta-thalassaemia. Indian J Med Res, 129(3), 242-8.
  4. , N. V. (1993). Use of fast protein size-exclusion liquid chromatography to study the unfolding of proteins which denature through the molten globule. Biochemistry, 32(48), 13288-98.
